  • 40G QSFP+ LX4 150m MMF / 2km SMF (FQ1340GD2)

  • Features
    • Hot pluggable QSFP+ form factor
    • Four CWDM lanes (1271nm, 1291nm, 1311nm, 1331nm) MUX / DEMUX design
    • Supports 44.8Gbps aggregate bit rates (up to 11.2Gbps per wavelength)
    • Transmission distance of 150m and 2km respectively on MMF(OM3) and SMF
    • Uncooled 4x10Gbps CWDM DFB transmitter and PIN photo-detector
    • Power Consumption < 3.5W typical
    • Single 3.3V power supply
    • XLPPI electrical interface
    • Duplex LC receptacles
    • Built-in Digital Diagnostic Monitoring functions
    • Compliant with 40G Ethernet IEEE802.3ba
    • Compliant with RoHS-6 (lead-free)
    • Operating Case Temperature:
      Commercial temperature range(COM): 0 to 70°C

    • 40GBASE-LX4 Ethernet Links
    • Infiniband QDR and DDR Links
    • Client-side 40G Telecom Links
    • Other Optical Links

  • Product Details
    Part Number
    Download Datasheet
    Data Rate
    Source Case Temp.
    DDM Others
    FQ1340GD2 40 0.15/2 1270 ~ 1330 DFB + PIN 0 ~ 70 Yes MMF/SMF, RoHS-6
    For further information, please contact us by email via
