• Hot pluggable
• QSFP+ End: Compliant with QSFP+ MSA specifications
• XFP End: Compliant with XFP MSA specifications
• Full-duplex 4 independent channels operating at 10Gbps
• Copper link length up to 5m and 10m respectively on passive and active
• 30 AWG to 24 AWG cable sizes available
• AC coupled inputs and outputs
• 100 Ohm differential impedance
• Low power consumption
• Single 3.3V power supply
• Metal enclosure for low EMI
• Compliant with SFF-8436 (QSFP+)
• Compliant with RoHS-6 (lead-free)
• Operating Case Temperature Range:
Commercial temperature range(COM): 0 to 70°C
• 40G / 10G Ethernet
• Other Optical Links
1. 30 AWG to 24 AWG cable sizes maybe available upon request.
2. Other customized lengths maybe available upon request.
3. Other customized cable color maybe available upon request.
4. For further information, please contact us by email via email@example.com.
