  • 400G QSFP-DD SR8 850nm 100m MMF (FQ85400GD1)

  • Features
    • Hot pluggable QSFP-DD form factor
    • Supports 400Gbps aggregate bit rates
    • Transmission distance of 70m and 100m respectively on OM3 and OM4
    • 8 channels 850nm VCSEL transmitter
    • 8 channels PIN photo-detector array
    • Internal CDR on both Transmitter and Receiver channel
    • Supports CDR bypass
    • Power Consumption < 9.0W
    • Single 3.3V power supply
    • Single MPO-24 receptacle
    • Built-in digital diagnostic functions
    • Compliant with 400G Ethernet IEEE 802.3bs
    • Compliant with RoHS-6 (lead-free)
    • Operating Case Temperature:
      Commercial temperature range(COM): 0 to 70°C

    Applications
    • 400GBASE-SR4 400G Ethernet
    • Other Optical Links

  • Product Details
    Part Number
    Download Datasheet
    Data Rate
    (Gbps)
    Reach
    (m)
    Wavelength
    (nm)
    Source Case Temp.
    (°C)
    DOM Others
    FQ85400GD1 400 100 850 VCSEL + PIN 0 ~ 70 Yes MMF, RoHS-6
    Notes:
    For further information, please contact us by email via sales@forara.com.
