Features
• Hot pluggable SFP28 form factor
• 1310nm DFB transmitter and PIN photo-detector
• Data rate up to 25.78Gbps bit rate
• Transmission distance of 20km on 9/125um SMF
• Power consumption < 1.5W
• Internal CDR on both Transmitter and Receiver channel
• Single 3.3V power supply
• Metal enclosure for lower EMI
• Duplex LC receptacle
• Built-in Digital Diagnostic Monitoring functions
• Compliant with IEEE802.3by 25GBASE-LR
• Compliant with SFF-8431, SFF-8432, SFF-8402 and SFF-8472
• Compliant with RoHS-6 (lead-free)
• Operating Case Temperature:
Commercial temperature range(COM): 0 to 70°C
Industrial temperature range(IND): -40 to 85°C
Applications
• 25GBASE-LR Ethernet
• High-speed Storage Area Networks
• Other Optical Links
