  • 10G BIDI XFP 80km Tx1490/Rx1550nm SMF (FXB45TGL8)

  • Features
    • Hot-pluggable XFP footprint
    • Uncooled 1490nm DFB Transmitter and 1550nm APD Receiver
    • Supports 9.95Gbps to 11.3Gbps bit rates
    • Transmission distance of 80km over 9/125um SMF
    • Power consumption < 2.0W
    • Metal enclosure for lower EMI
    • Simplex LC receptacle
    • Power supply: +1.8 V, +3.3 V
    • XFI Loopback Mode support
    • Built-in digital diagnostic functions
    • Compliant with XFP MSA
    • Compliant with IEEE 802.3ae
    • Compliant with RoHS-6 (lead-free)
    • Operating Case Temperature:
      Commercial temperature range(COM): 0 to 70°C
      Industrial temperature range(IND): -40 to 85°C

    Applications
    • 10GBASE-ZR at 10.3125Gbps
    • 10GBASE-ZW at 9.953Gbps
    • 1200-SM-LL-L 10G Fiber Channel
    • SONET OC-192 / SDH STM-64
    • Other Optical Links

  • Product Details
    Part Number
    Download Datasheet
    Data Rate
    (Gbps)
    Reach
    (km)
    Wavelength
    (nm)
    Source Case Temp.
    (°C)
    DDM Others
    FXB45TGL8 10 80 Tx1490/Rx1550 DFB + APD 0 ~ 70 Yes SMF, RoHS-6
    FXB45TGL8E 10 80 Tx1490/Rx1550 DFB + APD -10 ~ 85 Yes SMF, RoHS-6
    FXB45TGL8I 10 80 Tx1490/Rx1550 DFB + APD -40 ~ 85 Yes SMF, RoHS-6
    Notes:
    For further information, please contact us by email via sales@forara.com.
