  • 100G QSFP28 CWDM4 2km SMF (FQ13100G02C)

  • Features
    • Hot pluggable QSFP28 form factor
    • Supports 103.125Gbps aggregate bit rates (up to 25.78125 Gbps per wavelength)
    • Transmission distance of 2km on SMF
    • 4x25Gbps CWDM transmitter (1271nm, 1291nm, 1311nm, 1331nm)
    • 4x25Gbps electrical interface
    • Power Consumption < 3.5W
    • Single 3.3V power supply
    • CAUI-4 high speed electrical interface
    • Duplex LC receptacles
    • Built-in digital diagnostic functions
    • Compliant with 100G Ethernet IEEE802.3bm
    • Compliant with RoHS-6 (lead-free)
    • Operating Case Temperature:
      Commercial temperature range(COM): 0 to 70°C

    • 100G Ethernet Links
    • Infiniband QDR and DDR Interconnects
    • Datacenter and Enterprise Networking
    • Other Optical Links

  • Product Details
    Part Number
    Download Datasheet
    Data Rate
    Source Case Temp.
    DDM Others
    FQ13100G02C 100 2 1270 ~ 1330 DFB + PIN 0 ~ 70 Yes SMF, RoHS-6
