Features
• Hot pluggable electrical interface
• Supports 112.2Gbps aggregate bit rates (up to 28.05Gbps per wavelength)
• One port QSFP28 Tx/Rx, supports 100G QSFP28 LR4 / ER4
• Internal CDR circuits on both receiver and transmitter channels
• Without FEC (Forward Error Correction)
• Compliant with OTU4
• Single 3.3V power supply
• Power Consumption < 2.0W
• MDIO management interface
• Compliant with CFP2 Hardware Specification Version 1.0
• Compliant with RoHS-6 (lead-free)
• Operating Case Temperature:
Commercial temperature range(COM): 0 to 70°C
Applications
• 100G Ethernet Interconnects
• Other Optical Links
