  • 100G CFP to 100G QSFP28 Adapter (FCCVQSFP)

  • Features
    • Hot pluggable electrical interface
    • Supports 103.1Gbps to 112Gbps aggregate bit rates
    • Converts 10 bidirectional 10G lanes to 4 bidirectional 25G lanes
    • Transmission data rate up to 28Gbps per channel
    • One port QSFP28 Tx/Rx, supports 100G QSFP28 LR4 / ER4
    • Without FEC (Forward Error Correction)
    • Single 3.3V power supply
    • Power Consumption < 4.0W
    • MDIO management interface
    • Compliant with OTU4
    • Compliant to CFP Hardware Specification Version 1.4
    • Compliant to CFP MSA Management Interface Specification Version 2.2
    • Compliant with RoHS-6 (lead-free)
    • Operating Case Temperature:
      Commercial temperature range(COM): 0 to 70°C

    • 100G Ethernet Interconnects
    • Other Optical Links

  • Product Details
    Part Number
    Download Datasheet
    Data Rate
    Source Case Temp.
    DDM Others
    FCCVQSFP 100 as QSFP+ as QSFP+ N/A 0 ~ 70 Yes SMF, RoHS-6
    For further information, please contact us by email via
