  • 100G/112G QSFP28 LR4 20km SMF (FQ13112GL2)

  • Features
    • Hot pluggable QSFP28 form factor
    • Supports 103.1Gbps to 112.2Gbps aggregate bit rates (up to 28.05 Gbps per wavelength)
    • Transmission distance of 20km on SMF
    • 4x28Gbps EML-based LAN-WDM transmitter(1295.56, 1300.05, 1304.58, 1309.14nm)
    • 4x25Gbps electrical interface
    • Power Consumption < 3.5W
    • Single 3.3V power supply
    • CAUI-4 high speed electrical interface
    • Duplex LC receptacles
    • Built-in digital diagnostic functions
    • Compliant with 100G Ethernet IEEE802.3ba and IEEE 802.3bm
    • Compliant with RoHS-6 (lead-free)
    • Operating Case Temperature:
      Commercial temperature range(COM): 0 to 70°C

    Applications
    • 100GBASE-LR4 100G Ethernet
    • OTN OTU4
    • Infiniband QDR and DDR Interconnects
    • Datacenter and Enterprise Networking
    • Other Optical Links

  • Product Details
    Part Number
    Download Datasheet
    Data Rate
    (Gbps)
    Reach
    (km)
    Wavelength
    (nm)
    Source Case Temp.
    (°C)
    DDM Others
    FQ13112GL2 100/112 20 1294 ~ 1310 EML + PIN 0 ~ 70 Yes SMF, RoHS-6
    Notes:
    For further information, please contact us by email via sales@forara.com.
