  • 1.25G GBIC LX 1310nm 10km SC SMF (FG3124L1)

  • Features
    • Hot-pluggable GBIC footprint
    • 1310nm FP transmitter and PIN photo-detector
    • Data rate up to 1.25Gbps
    • Transmission distance of 10km over SMF
    • Low power dissipation
    • Single +5.0V power supply
    • Metal enclosure for lower EMI
    • Duplex SC receptacle
    • Compliant with GBIC Specification Rev. 5.5
    • Compliant with IEEE 802.3z Gigabit Ethernet 1000BASE-LX
    • Compliant with RoHS-6 (lead-free)
    • Operating Case Temperature:
      Commercial temperature range(COM): -5 to 70°C
      Extended temperature range (EXT): -10 to 85°C
      Industrial temperature range(IND): -40 to 85°C

    Applications
    • 1.0625Gb/s Fiber Channel
    • 1.25 Gigabit Ethernet
    • Other Optical Links

  • Product Details
    Part Number
    Download Datasheet
    Data Rate
    (Gbps)
    Reach
    (km)
    Wavelength
    (nm)
    Source Case Temp.
    (°C)
    DDM Others
    FG3124L1 1.25 10 1310 DFB + PIN -5 ~ 70 No SMF, RoHS-6
    FG3124L1I 1.25 10 1310 DFB + PIN -40 ~ 85 No SMF, RoHS-6
    Notes:
    For further information, please contact us by email via sales@forara.com.
